transom area
Next
Prev
electric on center seat which is in the forward position in this pic
front strap to keep it from sliding rearward and also the lock/cable we keep on it while at the marina.
front view of front saddle set (17.5 inches at outside edge and 6 inches up from bar to contact point) This is the measurement with boat on saddles so they are squished down an inch or so. 2 inches between saddles for keel clearance
transom area
typical radome clearance. There is a strap at the front to keep it from getting closer on the move
rear view of rear saddle set (20 inches at outside edge and 6 inches up from bar to contact point) This is the measurement with boat on saddles so they are squished down an inch or so. 4.5 inches for wheel clearance between saddles
daggerboard webbing tiedown on each side line up well with the roof rails (it is just loop of webbing and the knot at the top keeps it from being pulled down through)
Next
A

transom area

  • Media owner Aurelia
  • Date added
transom area
