(rogerbum) 6 switch electrical panel in cockpit. Top L is Man Fore Bilge, Top C is Man Aft Bilge, Top R is Auto Aft Bilge, Bottom L is cockpit lighting (12V rope light to be installed), bottom C is SpotLight, bottom R is new 12V outlet (to right of panel, below downrigger power)

  • Media owner rogerbum
  • Date added
(rogerbum) 6 switch electrical panel in cockpit. Top L is Man Fore Bilge, Top C is Man Aft Bilge, Top R is Auto Aft Bilge, Bottom L is cockpit lighting (12V rope light to be installed), bottom C is SpotLight, bottom R is new 12V outlet (to right of panel, below downrigger power)
