Cutty, Forward to Port. Wooden boat paddle held up under port forward deck. Access hatch to storage locker.
Next
Prev
The machine screws are 1-3/4" long and are nutted to hold the hatch in place, then nutted again with fender washers to hold the insulation in place. The perimeter of the sheet insulation is wedged in place by fit and the reverse angle of the hull.
Looking straight down the access hole and at the inside of the stem.
Cutty, forward to starboard. Wooden boat paddle held up under port forward deck. Access hatch to storage locker.
Cutty, Forward to Port. Wooden boat paddle held up under port forward deck. Access hatch to storage locker.
Looking straight down at the inside of the stem and a bit aft. The orange is the backside of the forward "V" storage locker bulkhead. There is about a 2" clearance under the "V" storage locker.
Looking up the inside of the stem and the insulation under the anchor locker and back to the "V" storage locker.
looking from within the hole, forward at the stem, and under the anchor locker.
Next
R

Cutty, Forward to Port. Wooden boat paddle held up under port forward deck. Access hatch to storage locker.

Cutty, Forward to Port.
Wooden boat paddle held up under port forward deck.
Access hatch to storage locker.
